FIB-X Services L.L.C.

Located in Plano,Texas and established in 2003, FIB-X is comprised of dedicated individuals with over 30 years experience in the art of FIB nano-fabrication.  We understand that in order for us to succeed, our customers must succeed.  This is why quality of service and attention to detail are the primary focus of this company.  FIB-X is constantly developing new techniques and expanding the knowledge base that is necessary for high yield design modifications in an ever increasingly difficult field.


We are continualy upgrading and maintining our equipment to keep up with our customers' demands and needs.

FEI Thermo Fisher Helios 660 G3

The FEI Helios 660 FIB is the Cadilac of Focused Ion Beam systems. Optimised for high resolution semiconductor operations digital rock data production. Equipped with MAPS mosaic tile stitching and Auto Slice & View 3D tomographic cube generating software, with simultaneous detector acquisitions, (BackScatter, Secondary,X-Ray) the Helios is a fantastic all in one nano-fabrication machine generating jaw-dropping datasets unlike anything you have seen before.


*Thru-Lens detectors (BSE & SE)
*Large Stage Range : 110 x 110 x 8mm
*Analytical WD 4mm
*ICE detector
*DBS GAD detector
*Largest Tilt Range -15 deg to 90 deg
*1kV Resolution 0.9 nm


The FEI Teneo SEM was designed for difficult to image samples, such as geological, biological, magnetic, and other non-conductive specimens. FEI Teneo’s in-column back scatter detector (BSE) and secondary electron detector (SE) are sensitive enough to obtain simultaneous high resolution and contrast imaging at 500V. Because of the high beam current range (up to 400nA) and detector sensitivity, we are able to perform efficient 2D mapping with exceptional image resolution. By giving you more data at lower costs, FIB-X wants to change how you feel about digital rock.


*In-Lens detectors (BSE & SE)
*NICol SEM Column
*Large Stage Range : 110 x 110 x 65mm
*Analytical WD 10mm
*STEM detector
*DBS GAD detector
*Largest Tilt Range -15 deg to 90 deg
*1kV Resolution 1.4 nm with BSD

FEI DB235 Dual Beam

This is a highly analytical tool allowing you to request precise cross sections and receive high quality SEM images. It is a dual column FIB with an ion beam column and a SEM column at a 52 degree angle from eachother which allows for simultanious cutting and SEM imaging under vacuum enabling efficient defect hunting and minimizing contamination. Once we find your defect we can use our Bruker EDS insitu to determine what contaminants we are seeing in the cross section.


*Schottky FEG SEM
*FEI Magnum FIB Column
*Bruker Quantax 200 EDS (elemental Analysis)
*Pt deposition
*Gas assisted etch (metal and dielectric)

DCG P3X Circuit Mod Tool

Regarded as one of the most efficient ciruit modification tools, FIB-X has 2 P3X systems installed that are capeable of 45nm copper top down circuit edits all the way up to Gold GaAs devices.


*< 5 nm Resolution
*CAD navigation (both Schlumberger and Knights)
*Pt deposition
*Gas assisted etch (metal and dielectric)
*Insulator deposition (Si02)
*Copper Etch
*8” wafer capability

Fischione Model 1060

The Fischione Model 1060 SEM mill is perfectly designed for sample preparation of geological samples, such as shale. An extremely smooth surface is paramount when obtaining high resolution BSE SEM imaging on non-conductive geological samples. Two independent TrueFocus ion sources with adjustable beam diameters give FIB-X unmitigated control of the mill rate when preparing a sensitive semiconductor sample or a geological sample. The Fischione Model 1060 SEM mill can prepare samples up to 25 mm (diameter) x 15 mm (height). The relatively large sample accommodation allows for an opportunity to investigate more locations across your sample.


*Two TrueFocus ion sources
*25mm (diameter) x 15mm (height)
*360 deg sample rotation
*Variable energy 100eV to 6.0 keV
*Specimen rocking
